| Specification | Details |
|---|---|
| Size Range | 1/2″ to 12″ Flanged |
| Temperature Range | -50°C to 300°C for Soft Seated Valves. Contact Works for Special Requirement |
| Pressure Class | 150#, 300# |
| Media | Air / Water / Oil & Gas |
| Body Material | CAST IRON (CI), DUCTILE IRON (DI), S.G. IRON (SGI), WCB, CF8, CF8M, CF3M, SS 304L, DUPLEX, HAST ALLOY, MONEL |
| Ball Material | CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M |
| Ball Type | Hollow & Solid |
| Stem Material | AISI 410, SS 304, SS 316, SS 304L, SS 316L, Duplex 2205, Duplex 2507, Monel |
| Seat Material | PTFE, RPTFE, CFT, GFT, Modified PTFE, AIRA-250, NYLON, DEVLON, PEEK |
| Flange Drilling | ASME B 16.5 Class 150# / DIN / JIS |
| Certification | Design CE Approved, SIL3 Approved, IBR, POD, API 6D, API 607 |
| Note | PEEK Seat is not possible |
An ISO 5211 Direct Mounting Pad, V-type Cheuron Gland Packing, Which Leads To Leak After Thousands Of Cycle, Low Torque.
