| Specification | Details |
|---|---|
| Temperature Range | -20°C to 90°C |
| Inlet Air Supply | 2.5 to 4 KG/CM² |
| Stem Movement | Linear |
| Actuator Action | Direct Acting / Reverse Acting |
| Air Fail Position | Stem Extended / Stem Retracted |
1. Flexible Diaphragm: The core component that converts pneumatic pressure into motion, ensuring smooth and reliable operation.
2. Spring Return: Includes a spring mechanism that returns the actuator to a default position when pressure is removed, ensuring fail-safe operation.
3. Safety: With the ability to return to a default position during a failure, pneumatic linear diaphragm actuators help maintain system safety and prevent damage.
1. Flexible Diaphragm: The core component that converts pneumatic pressure into motion, ensuring smooth and reliable operation.
2. Spring Return: Includes a spring mechanism that returns the actuator to a default position when pressure is removed, ensuring fail-safe operation.
3. Safety: With the ability to return to a default position during a failure, pneumatic linear diaphragm actuators help maintain system safety and prevent damage.
