| Specification | Details |
|---|
| Size Range | 2″ to 48″ (50MM to 1200MM) |
| Temperature Range | Up to 250°C |
| Pressure Class | PN 20 |
| Shutoff Rating | Tight Shut Off |
| Body Style | Double Flanged |
| Flange Drilling | 150#, 300#, AWWA, Series-A, Series-B, EN 1092-1 |
| Body Materials | WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY – 20 |
| Stem Materials | SS 304 / 316 / 410 / 17-4 PH / 316L / NITRONIC – 50 / DUPLEX 4A / 5A / 6A / 7A |
| Seat Materials | PTFE, RPTFE, GFT, CFT, aira 250, TFM – 1600 |
| Disc Materials | WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY – 20 |
| Design Standard | BSEN 593, ISI 3095, API 609, AWWA C – 504 |
| Testing Standard | API 598 / BSEN – 12266-1 / AWWA C – 504 |
| Face to Face | API – 609 / BSEN 558 / AWWA C – 504 / 516 |
1 – Double Offset Design: Enhances sealing efficiency and reduces seat wear, ensuring long-term reliability and performance.
2 – Teflon Seating: Provides superior chemical resistance and a tight seal, minimizing leakage and extending the valve’s lifespan.
3 – Double Flanged Ends: Facilitates easy and secure installation with strong, leak-proof connections to piping systems.
4 – Corrosion Resistance: The valve is engineered to withstand harsh environments and corrosive fluids, ensuring durability and extended service life.
5 – High Performance: Designed for smooth operation and control of various fluids, including those at high pressures and temperatures.
6 – Low Maintenance: The robust construction and Teflon seating reduce the need for frequent maintenance, lowering overall operational costs.
