| Specification | Details |
|---|
| Size Range | 3″ to 60″ (80MM to 1500MM) |
| Temperature Range | Up to 220°C |
| Pressure Class | PN 50 |
| Shutoff Rating | Tight Shut Off |
| Body Style | Wafer Type |
| Flange Drilling | 150#, 300#, AWWA, Series-A, Series-B, EN 1092-1, EN 1092-2 |
| Body Materials | WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY – 20 |
| Stem Materials | SS 304 / 316 / 410 / 17-4 PH / 316L / NITRONIC – 50 / DUPLEX 4A / 5A / 6A / 7A |
| Seat Materials | EPDM, EPDM – H, VITON |
| Disc Materials | WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY – 20 |
| Design Standard | BSEN 593, ISI 3095, API 609, AWWA C 504 |
| Testing Standard | API 598, BSEN – 12266-1, AWWA C 504 |
| Face to Face | API – 609, BSEN 558, AWWA C 504 / 516 |
| End Connection | 150#, 300# |
1 – Double Offset Design: Reduces friction and wear, enhancing performance and extending valve life.
2 – Rubber Seat: Provides a reliable, tight seal to minimize leakage.
3 – Wafer Type Construction: Facilitates easy installation between flanges and saves space.
4 – Versatile Application: Suitable for water, wastewater, and other fluid handling systems.
5 – Durability: Designed for long-lasting performance and cost-effectiveness.
6 – Compact and Lightweight: Ideal for various industrial and commercial settings.
