| Specification | Details |
| Size Range | 3″ to 60″ (80MM to 1500MM) |
| Temperature Range | Up to 220°C |
| Pressure Class | PN 50 |
| Shutoff Rating | Tight Shut Off |
| Body Style | Double Flanged |
| Flange Drilling | 150#, 300#, AWWA, Series-A, Series-B, EN 1092-1, EN 1092-2 |
| Body Materials | WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY – 20 |
| Stem Materials | SS 304 / 316 / 410 / 17-4 PH / 316L / NITRONIC – 50 / DUPLEX 4A / 5A / 6A / 7A |
| Seat Materials | EPDM, EPDM – H, VITON |
| Disc Materials | WCB, CF8, CF8M, CF3M, DUPLEX, ALLOY – 20 |
| Design Standard | BSEN 593, ISI 3095, API 609, AWWA C 504 |
| Testing Standard | API 598, BSEN – 12266-1, AWWA C 504 |
| Face to Face | API – 609, BSEN 558, AWWA C 504 / 516 |
| End Connection | Flanged End 150#, 300# |
1 – Double Offset Design: Reduces friction and wear, promoting smooth operation and extending valve life.
2 – Rubber Seat: Ensures a tight, reliable seal to prevent leakage.
3 – Double Flanged Construction: Provides secure, stable installation and alignment in piping systems.
4 – Robust Performance: Ideal for handling water, wastewater, and various other fluids.
5 – Durability: Built to withstand demanding industrial environments with minimal maintenance.
6 – Versatility: Suitable for a range of applications requiring reliable flow control.
