| Specification | Details |
|---|
| Design & Manufacturer | ASME B16.34 / BS EN ISO 17292 |
| Valve Face-to-Face Dimension | As Per Manufacturing Standard |
| Inspection & Testing | API 598 / ISO-5208 / BS EN 12266-1 |
| Flange Standard Conformity | ASME B16.5 Class 150 |
| End Connection | Screwed End |
| Size Range | 1/2″ to 4″ Screwed |
| Temperature Range | PTFE: Up to 180°C / RPTFE: Up to 220°C / AIRA-250 |
| Pressure Class | 150# |
| Media | Air / Water / Oil / Gas |
| Body Material | WCB, CF3, CF8, CF8M, CF3M, Duplex, Hast Alloy, Monel, Ductile Iron, S.G Iron |
| Ball Material | CF3, CF3M, CF8, CF8M, WCB + ENP, Hast Alloy, Duplex |
| Ball Type | Hollow / Solid Ball |
| Stem Material | CF3, CF3M, CF8, CF8M, 410, Duplex 2205, Duplex 2507, Monel, 17-4 PH |
| Seat Material | PTFE, RPTFE, Modified PTFE, AIRA-250 |
| Certification | Design CE Approved, POD, Fire Safe Design |
1 – Antistatic Design.
2 – Locking Handle Available.
3 – High Performance Ball Valve.
4 – ISO 5211 Mounting.
5 – Quick In Action.
6 – Blow Outproof Stem.
7 – High Cycle Life.
