| Specification | Details |
|---|
| Design & Manufacturer | ASME B16.34 / BS EN ISO 17292 |
| Valve Face To Face Dimension | As per Manufacturing |
| Inspection & Testing | API 598 / ISO-5208 / BS EN 12266-1 |
| Size Range | 1/2″ to 4″ |
| Temperature Range | -25°C to 180°C for Soft Seated Valves. Contact Works for Special Requirements (-195°C, -45°C, +300°C on Request) |
| Pressure Class | 150# |
| Stem Material | AISI 410, AISI 304, AISI 316, AISI 304L, AISI 316L, Duplex 2205, Duplex 2507, Monel |
| Seat Material | PTFE, RPTFE, CFT, GFT, Modified PTFE, AIRA-250, Nylon, Devlon, PEEK |
| Leakage Class | ISO 5208 Class VI / ASME B16.104, ANSI FCI 70-2 (Bubble Tight Shutoff) |
| End Connection | ASME B16.25 Butt-Weld Ends |
| Media | Air / Water / Oil & Gas |
| Body Material | WCB, CF8, CF8M, CF3M, SS 304L, Duplex, Hast Alloy, Monel |
| Ball Material | CF8, CF8M, WCB + ENP, Hast Alloy, Duplex, Monel, CF3M |
| Ball Type | Hollow & Solid |
| Certification | Design CE Approved, SIL3 Approved, IBR Approved, POD Approved, Fire Safe Approved |
1- High Cycle Life.
2- Antistatic Design & Fire Safe Design As Per API 607.
3- Blow Outproof Stem.
4- Locking Handle Available.
5- ISO 5211 Mounting Pad Available.
6- V-type Cheuron Gland Packing, Which Leads To Zero Leak After Thousand Of Cycle.
