| Specification | Details |
|---|---|
| Design & Manufacturer | API 599 / BS 5353 |
| Inspection & Testing | API 598 / EN 12266-1 |
| Leakage Class | Class VI ISO – 5208 |
| End Connection | Screw End, BSP/NPT, Flanged, Flanged Type Reduce Bore, Jacketed Type Flanged End |
| Size Range | 1/2″ to 2″ |
| Temperature Range | -50°C to 300°C for Soft Seated Valves. Contact Works for Special Requirement |
| Working Pressure | Up to 10 Kg/Cm² |
| Pressure Class | 150# |
| Media | Air, Water, Oil, Gas, Nitrogen, Chemical |
| Body Material | Cast Iron (CI), Ductile Iron (DI), S.G. Iron (SGI), WCB, CF8, CF8M, CF3M, SS 304L, Duplex, Hast Alloy, Monel |
| Plug Material | CF8, CF8M, WCB + ENP, Hast Alloy, Duplex, Monel, CF3M |
| Seat Material | PTFE, RPTFE, CFT, GFT, TFM-1600, AIRA-250 |
| Flange Drilling | ASME B 16.5 Class 150# / 300# |
| Certification | Design CE Approved, SIL3 Approved, IBR Approved, Fire Safe Approved, ISO Approved |
| Face to Face | ASME B 16.10 |
1 – Easy Operation 0° – 90°
2 – Compact And Robuts Body Design (One – Piece Cast Body)
3 – PTFE – Sleeve Entirely Retained By 360° Lips Around The Ports
4 – Secondary Seal At The Cover – Also In FIRE SAFE – Design Available (On Request)
5 – PTFE – Sleeve Acts As Primary Seal In The Waterway And To Atmoshere
6 – Conical Plug Shape Grants Low Operation Torques And Vertical Adjustment Possibility
7 – Low Weight
1 – Easy Operation 0° – 90°
2 – Compact And Robuts Body Design (One – Piece Cast Body)
3 – PTFE – Sleeve Entirely Retained By 360° Lips Around The Ports
4 – Secondary Seal At The Cover – Also In FIRE SAFE – Design Available (On Request)
5 – PTFE – Sleeve Acts As Primary Seal In The Waterway And To Atmoshere
6 – Conical Plug Shape Grants Low Operation Torques And Vertical Adjustment Possibility
7 – Low Weight
