| Specification | Details |
|---|---|
| Design & Manufacturer | ASME B 16.34 / BS EN ISO 17292 |
| Valve Face To Face Dimension | ASME B 16.10 / BS EN ISO 17292 |
| Inspection & Testing | API 598 / ISO – 5208 / BS EN 12266-1 |
| Size Range | 1/2″ to 2″ Floating, 2.1/2” to 6” Trunnion |
| Temperature Range | -50°C to 300°C for Soft Seated Valves (Contact Works for Special Requirements – On Request) |
| Ball Material | CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M |
| Ball Type | Hollow & Solid |
| Flange Drilling | ASME B 16.5 Class 150#/ 300#/ Din/ JIS |
| Leakage Class | ISO 5208 Class VI / FCI – 70-2 / ASME, ANSI B 16,16.104 (Bubble Tight Shut Off) |
| End Connection | ASME B 16.5 Class 600 |
| Pressure Class | 600# |
| Media | Air / Water / Oil & Gas |
| Body Material | DUCTILE IRON (DI), S.G. IRON (SGI), WCB, CF8, CF8M, CF3M, SS 304L, DUPLEX, HAST ALLOY, MONEL |
| Stem Material | AISI 410, AISI 304, AISI 316, AISI 304L, AISI 316L, Duplex 2205, Duplex 2507, Monel |
| Seat Material | PTFE, RPTFE, CFT, GFT, Modified PTFE, AIRA-250, Nylon, Devlon, PEEK |
| Certification | Design CE Approved, SIL3 Approved, POD |
Fully Compliant To ASME B16.34 & API 608, ISO 5211 Mounting Pad Bolt Pattern, Slot Vented Ball For Thermal Expansion, Anti Static Grounded Ball & Stem, Blow-Out Proof Stem Design, Ring Joint , Tonge & Grove Joint Flange Available, Also Manufacture Special Grade MOC Like Supen Duplex,Hast Alloy Etc, Ball Seal: RPTFE, TFM, PEEK.
