| Specification | Details |
|---|---|
| End Connection | Screwed End 150# |
| Size Range | 3/8″ To 4″ Screwed End |
| Temperature Range | 85°C Max. (High Temperature On Request) |
| Pressure Class | 0 To 5 BAR |
| Media | Vacuum Plants, Pump Seal Water, Low Pressure Water |
| Body Material | CF8, CF3M, CF8M |
| Seat Material | NBR, Viton, Hi-Netra |
| Certification | CE |
1 – 2/2 Way Design: Manages fluid flow with a two-port configuration for reliable on/off control.
2 – Normally Closed/Normally Open Options: Available in both normally closed (NC) and normally open (NO) versions to fit different system requirements.
3 – Screwed Connections: Features threaded fittings for easy, secure installation.
4 – Automation Ready: Electrically actuated for precise and automated operation.
5 – Durable Construction: Made from high-quality materials like brass or stainless steel, ensuring long-term performance and resistance to corrosion.
6 – Compact and Efficient: Designed to perform well in space-constrained environments while maintaining reliability.
7 – Versatile Fluid Compatibility: Suitable for a wide range of fluids, including air, water, and chemicals.
8 – Low Maintenance: Engineered for minimal upkeep, reducing maintenance needs and operational costs.
9 – Fast and Reliable Switching: Ensures quick response times for effective system control.
1 – 2/2 Way Design: Manages fluid flow with a two-port configuration for reliable on/off control.
2 – Normally Closed/Normally Open Options: Available in both normally closed (NC) and normally open (NO) versions to fit different system requirements.
3 – Screwed Connections: Features threaded fittings for easy, secure installation.
4 – Automation Ready: Electrically actuated for precise and automated operation.
5 – Durable Construction: Made from high-quality materials like brass or stainless steel, ensuring long-term performance and resistance to corrosion.
6 – Compact and Efficient: Designed to perform well in space-constrained environments while maintaining reliability.
7 – Versatile Fluid Compatibility: Suitable for a wide range of fluids, including air, water, and chemicals.
8 – Low Maintenance: Engineered for minimal upkeep, reducing maintenance needs and operational costs.
9 – Fast and Reliable Switching: Ensures quick response times for effective system control.
